se:do pro 2
Well-proven ergonomics in a modular system – convincing in price-performance
Modular system
High flexibility in terms of areas of application and users, as individual components can be customised within the modular system.
Comfortable and ergonomic sitting thanks to application-specific mechanisms
Automatic weight system
“Similar” mechanism with weight adjustment and automatic seat tilt up to 5°
• for non-territorial areas of use
• lockable in 4 different positions
• opening angle: 0, 8, 16 and 26°
“Similar” mechanism with weight adjustment and automatic seat tilt up to 5°
• for light users and non-territoria4 Anschlägen feststellbar
• lockable in 4 different positions
• opening angle: 0, 8, 16 and 26°
Individual weight adjustment
“Similar” mechanism with individual weight adjustment, without forward tilt
• for territorial areas of use
• lockable in 3 positions
• opening angle: 26°
Similarmechanik mit individueller Gewichtseinstellung und Sitzneigeverstellung 4°
• for territorial areas of use
• lockable in 3 positions
• opening angle: 26°
Two backrest versions
Fully upholstered
Membrane
Versions and models
Office chair
(5-star base)
Counter chair
(5-star)
Visitor chair
(cantilever chair)
Visitor chair
(4-leg)
Options/accessories
- Lumbar support depth adjustment
Seat depth adjustment (70 and 100 mm) - Retrofittable neck support with coat hanger, as a set
- Project neck support, membrane-covered and retrofittable
- Retrofittable coat hanger
Options
| standard | optional | |
|---|---|---|
| Upholstery | Seat upholstered, backrest with membrane cover Seat and backrest upholstered | Different cover for backrest |
| Membrane | Black | Grey, blue, olive green |
| Model colour/plastic parts | Black | |
| Lumbar support | No lumbar support | Lumbar support depth adjustment |
| Armrests | Without armrests | 2D armrests with plastic covers Height-adjustable plastic armrests 3D armrests with plastic covers, width adjustable 3D armrests with PUR covers, width adjustable 4D armrests with soft-touch covers 4D armrests with 360° rotable soft-touch covers |
| Seat | Standard seat | Sliding seat (70 mm adjustment range) |
| Mechanism | Similar mechanism with automatic weight adjustment | Similar mechanism with automatic weight adjustment for light persons Similar mechanism with individuel weight adjustment Similar mechanism with individuel weight adjustment and forward tilt |
| Seat height-adjustment | Gaslift | Sedo-Lift mechanism lll |
| Base | 5-star plastic base, black | 5-star aluminium base, black, wihte aluminium, polished |
| Castors | Hard castors for soft flooring | Soft castors for hard flooring |
| Fire protection | Fire protection vrsion in combination with the cover fabrics Fame, One or Step | |
| Accessories | Coat hanger Neck support with height and tilt adjustment in black imitation leather Neck support with height and tilt adjustment, membrane black, fire restistant Set neck support/coat hanger Model prepared for retrogitting the accessories |
Technical Specifications
| Backrest | – Large, ergonomically shaped backrest, suitable for any body size, plastic frame in the model colour – Membrane version: mesh cover made from self-supporting knitted fabric – Upholstered version: upholstered backrest (moulded foam in PU with Sedus cover fabrics, attached all round without metal by means of sewn-on piping tape), upholstery thickness 55 mm – Height adjustment of backrest 80 mm, optional lumbar support depth adjustment (membrane version 12 mm, upholstered version 25 mm by means of integrated air cushion) – Optional neck support with height and tilt adjustment, covered with black imitation leather or with black mesh – Optional coat-hangers available individually or as a set with neck support |
| Armrests | – Code 3611: height-adjustable plastic armrests – Code 3211: 2D armrests – height- and width-adjustable – Code 3911: 3D armrests with plastic covers, width adjustable without tools – Code 3914: 3D armrests with soft-touch covers, width adjustable without tools – Code 3414: 4D armrests with soft-touch covers, height- and width-adjustable, movable pad, armrest support width adjustment, no tools required – Code 3424: 4D armrests with 360° rotatable soft-touch covers, height- and width-adjustable, movable pad, armrest support width adjustment, no tools required |
| Mechanism | – Synchron mechanism with automatic user weight recognition with smooth force transmission in black – Seat and backrest move completely synchronously with the body – Synchronicity relationship between seat and backrest 1:3,5 – Automatic adaptation to different users‘ body weights, version for light persons available as an option – Backrest tilt mechanism: 34°, locking in foremost position possible or additional restriction of backrest movement at 8, 16 and 26° – Automatic forward tilt (resulting from a shift in the user‘s weight) of up to 5° – Optional, Synchron mechanism with individual weight adjustment in black, backrest tilt mechanism: 30°, locking in 3 positions: in upright, middle and in leaned far back (30°) position, seat can be optionally adjusted by up to 5° in seat inclination for pressure relief in the thighs |
| Seat | – Ergonomically and anatomically shaped 5-zone seat ensures even pressure distribution and long-lasting sitting comfort for any body size – Shaped foam (polyurethane foam) – Foam thickness 45 mm, upholstery thickness 45 mm |
| Seat height-adjustment | – Continuous gas spring height adjustment – Mechanical gas spring: Full suspension of the body weight even in the bottom seat position due to pneumatic locking, practically wear-free, no failure or gas spring replacement |
| Base | – 5-star plastic base or 5-star aluminium base – Hard or soft castors with 65 mm diameter |
| User weight | – Recommended for user weights up to 150 kg |
| Warranty | – 5 years – 30 years for Sedo-Lift mechanism |
